Bluetooth LE

Enabling robust, ultra-low power wireless connectivity

The go-to choice for developers

Trusted by thousands of developers and holding a 40% market share, Nordic’s Bluetooth® LE solution is the go-to choice, leading to over two million wireless SoC (System-on-Chip) shipments daily into innovative IoT products worldwide.

Why choose Nordic's Bluetooth LE solution?

Strong wireless SoC portfolio: Our extensive selection of ultra-low power wireless SoC options features scalable memory configurations and feature sets covering a wide range of requirements. This also provides flexibility during development if memory or feature requirements change unexpectedly.

Ultra-low-power MCU functionality and 2.4 GHz radio: Our small ultra-low-power wireless SoC options integrate high-efficiency MCU (Microcontroller Unit) functionality and a high-performance multiprotocol 2.4 GHz radio, along with powerful peripherals, enabling you to build the smallest, most power-efficient IoT products.

Fully-featured certified Bluetooth LE protocol stack: As one of the major contributors to the development of the Bluetooth standard, we ensure our Bluetooth Low Energy stack supports all mandatory and optional features. With full reusable certification, our stack delivers robust Bluetooth LE communication with industry-leading interoperability.

Proven quality, reliability, and interoperability: Backed by thousands of developers and billions of wireless SoC shipments, our solution provides unmatched quality and reliability. Our Bluetooth LE protocol stack delivers verified interoperability with everything from smartphones to tablets and smartwatches, minimizing costly returns and protecting your IoT product’s reputation.

Made for developers: Our easy-to-use solution features powerful software and tools, technical support for all, comprehensive documentation, and hands-on online courses, enabling you to focus on creating features that make your IoT product stand out.

nRF54L Series

Next-level wireless SoCs


The nRF54L Series takes the popular nRF52 Series to the next level and is designed for the next-generation Bluetooth LE products. It integrates a new ultra-low-power 2.4 GHz radio and multi-purpose MCU functionality, featuring a 128 MHz Arm Cortex-M33 processor, doubling the processing power and tripling the processing efficiency.

The broad range of wireless SoCs in the nRF54L Series offers a selection of memory size options, from 0.5 MB to 2 MB NVM and 96 KB to 512 KB RAM, making it suitable for a wide range of Bluetooth LE applications.

Bluetooth LE product series



nRF54H Series




nRF54L Series




nRF53 Series






nRF52 Series



nRF52 Series logo_2.png

Wireless SoCs

nRF54H20

nRF54LM20A, nRF54LM20B, nRF54L15, nRF54L10, nRF54L05, nRF54LV10A

nRF5340

 nRF52840, nRF52833, nRF52832, nRF52820, nRF52811, nRF52810, nRF52805

Processor

2x Arm Cortex-M33, up to 320 MHz

128 MHz Arm Cortex-M33

2x Arm Cortex-M33, up to 128 MHz

64 MHz Arm Cortex-M4

NVM

2 MB

Up to 2.0 MB

1 MB + 256 KB

Up to 1 MB

RAM

1 MB

Up to 512KB

512 KB + 64 KB

Up to 256 KB

Bluetooth LE

Yes

Yes

Yes

Yes

Bluetooth Channel Sounding

Yes, pending software

Yes





TX power

10 dBm

Up to 8 dBm

3 dBm

Up to 8 dBm

RX sensitivity

-100 dBm

-96 dBm

-98 dBm

Down to -97 dBm

AI accelerator



128 MHz Axon NPU





RISC-V coprocessor



128 MHz FLPR





Processing performance - CPU running CoreMark from NVM

320 MHz FLPR + 16 MHz PPR

2.6 mA

3.3 mA

3.3 mA

Processing efficiency

TBC

20 µA / MHz

 26 µA / MHz

52 µA / MHz

Power consumption: Bluetooth LE advertising with default parameters

TBC

45 µA

76 µA

94 µA

Sleep power consumption: System ON, 256 KB RAM retention

TBC

3.0 µA

1.7 µA (64 KB network core RAM retained)

2.4 µA

Sleep power consumption: System OFF with GRTC wakeup

TBC

0.8 µA

N/A (GRTC unavail.)

 N/A (GRTC unavail.)

Standard peripherals and interfaces

Yes

Yes

Yes

Yes

Highlighted digital interfaces

High-speed SPI/UART, high-speed USB, QSPI, CAN-FD, EXMIF

High-speed SPI/UART, high-speed USB, sQSPI (SoftwarePeripheral)

High-speed SPI, full-speed USB, QSPI

High-speed SPI, full-speed USB, QSPI

Highlighted peripherals

14-bit ADC, Global RTC

14-bit ADC, Global RTC

12-bit ADC

12-bit ADC

Isolation

Secure Domain and TrustZone

TrustZone

TrustZone



Cryptographic accelerator

Yes, with side-channel leakage protection

Yes, with side-channel leakage protection

Yes

Yes

Tamper detectors

Yes

Yes





GPIOs

64

Up to 66

48

Up to 48

Neuton edge AI models

Yes

Yes

Yes

Yes

Compatible PMICs

nPM1300, nPM1100, nPM6001

nPM1300, nPM1100, nPM6001

nPM1300, nPM1100, nPM6001

nPM1300, nPM1100, nPM6001

nRF Cloud Services

Yes

Yes

Yes

Yes

nRF54L Series

nRF54LM20A SoC

Ultra-low-power wireless SoC supporting Bluetooth LE, Channel Sounding, Bluetooth Mesh, Zigbee, Thread, Matter, Aliro, and 2.4 GHz proprietary protocols.

128 MHz Arm Cortex-M33
2 MB NVM, 512 KB RAM
High-speed USB

Read more

nRF54LM20B SoC

Ultra-low-power wireless SoC with integrated Axon NPU, for hardware-accelerated edge AI applications, supporting Bluetooth LE, Channel Sounding, Bluetooth Mesh, Zigbee, Thread, Matter, Aliro, and 2.4 GHz proprietary protocols.

128 MHz Arm Cortex-M33
2 MB NVM, 512 KB RAM
128 MHz integrated Axon NPU
High-speed USB

Read more

nRF54LV10A_WLCSP_1.93x2.29_stacked nRF54LV10A SoC

Low-voltage, ultra-low-power wireless SoC, supporting Bluetooth® LE and 2.4 GHz proprietary protocols, compatible with silver oxide batteries.

128 MHz Arm Cortex-M33
1 MB NVM, 192 KB RAM
1.2-1.7 V supply voltage
<50 nA hibernation mode

Read more

nRF54L15_QFN48_6x6_stacked_web.png nRF54L15 SoC

Ultra-low-power wireless SoC supporting Bluetooth LE, Bluetooth Channel Sounding, Bluetooth Mesh, Zigbee, Thread, Matter, Amazon Sidewalk and 2.4 GHz proprietary protocols

128 MHz Arm Cortex-M33
1.5 MB NVM, 256 KB RAM

Read more

nRF54L10_QFN48_6x6_stacked_web.png nRF54L10 SoC

Ultra-low-power wireless SoC supporting Bluetooth LE, Bluetooth Channel Sounding, Bluetooth Mesh, Zigbee, Thread, Matter, Amazon Sidewalk and 2.4 GHz proprietary protocols

128 MHz Arm Cortex-M33
1.0 MB NVM, 192 KB RAM

Read more

nRF54L05_QFN48_6x6_stacked_web.png nRF54L05 SoC

Ultra-low-power wireless SoC supporting Bluetooth LE, Bluetooth Channel Sounding, Bluetooth Mesh, Zigbee, Thread and 2.4 GHz proprietary protocols

128 MHz Arm Cortex-M33
1.5 MB NVM, 96 KB RAM

Read more
See all

nRF54H Series

Sampling to selected customers now

nRF54H20 wireless SoC

Sampling now: Revolutionary multiprotocol and multiprocessor SoC with world-leading processing power and efficiency, ample memory, record-breaking radio, and state-of-the-art security.

Read more

Product overview webinar

All Bluetooth LE on-demand webinars

nRF53 and nRF52 Series Bluetooth LE SoCs

  nRF5340 SoC nRF52840 aQFN73 SoC nRF52833 SoC nRF52832 SoC nRF52820 SoC nRF52811 SoC nRF52810 SoC nRF52805 SoC front and back
  nRF5340 SoC nRF52840 SoC nRF52833 SoC nRF52832 SoC nRF52820 SoC nRF52811 SoC nRF52810 SoC nRF52805 SoC
CPU
CPU

128 MHz Arm Cortex-M33
+
64 MHz Arm Cortex-M33

64 MHz Arm Cortex-M4 with FPU

64 MHz Arm Cortex-M4 with FPU

64 MHz Arm Cortex-M4 with FPU

64 MHz Arm Cortex-M4

64 MHz Arm Cortex-M4

64 MHz Arm Cortex-M4

64 MHz Arm Cortex-M4
Flash
Flash

1 MB + 256 KB

1 MB

512 KB

512/256 KB

256 KB

192 KB

192 KB

192 KB
RAM
RAM

512 KB + 64 KB

256 KB

128 KB

 64/32 KB

32 KB

24 KB

24 KB

24 KB
Arm TrustZone
Arm TrustZone

Yes














Arm CryptoCell
Arm CryptoCell

312

310












Root-of-Trust
Root-of-Trust

Yes

Yes












Secure key storage
Secure key storage

Yes














High-Speed SPI
High-Speed SPI

Yes

Yes

Yes










TWI/SPI/UART
TWI/SPI/UART

4xTWI/SPI/UART + TWI/SPI/UART

2xTWI/SPI, SPI, 2xUART

2xTWI/SPI, SPI, 2xUART

2xTWI/SPI, SPI, UART

2xTWI/SPI, UART

TWI/SPI, SPI, UART

TWI, SPI, UART

TWI, SPI, UART
QSPI
QSPI

Yes

Yes












USB
USB

Yes

Yes

Yes



Yes






PWM, PDM, I2S
PWM, PDM, I2S

Yes

Yes

Yes

Yes



PWM, PDM

PWM, PDM


ADC, Comparator
ADC, Comparator

Yes

Yes

Yes

Yes

COMP

ADC, COMP

ADC, COMP

ADC
Operating temperature
Operating temperature

-40 to 105 °C

-40 to 85 °C

-40 to 105 °C

-40 to 85 °C

-40 to 105 °C

-40 to 85 °C

-40 to 85 °C

-40 to 85 °C
Supply voltage range
Supply voltage range

1.7 to 5.5 V

1.7 to 5.5 V

1.7 to 5.5 V

1.7 to 3.6 V

1.7 to 5.5 V

1.7 to 3.6 V

1.7 to 3.6 V

1.7 to 3.6 V
Packages
Packages

7x7 mm
aQFN94
(48 GPIOs)

4.4x4.0 mm
WLCSP95
(48 GPIOs)

7x7 mm
 aQFN73
 (48 GPIOs)

 6x6 mm
 QFN48
 (30 GPIOs)

 3.5x3.6 mm
 WLCSP94
 (48 GPIOs)

7x7 mm
aQFN73
(42 GPIOs)

5x5 mm
QFN40
 (18 GPIOs)

3.2x3.2 mm
WLCSP
(42 GPIOs)

6x6 mm
QFN48
(32 GPIOs)

3.0x3.2 mm
WLCSP50
(32 GPIOs)

5x5 mm
QFN40
(18 GPIOs)

6x6 mm
QFN48
(32 GPIOs)

5x5 mm
QFN32
(17 GPIOs)

2.48x2.46 mm
WLCSP33
(15 GPIOs)

6x6 mm
QFN48
(32 GPIOs)

5x5 mm
QFN32
(16 GPIOs)

2.48x2.46 mm
WLCSP33
(15 GPIOs)

2.48x2.46 mm
WLCSP28
(10 GPIOs)

nRF53 Series

nRF5340 SoC

Dual-core Bluetooth SoC supporting Bluetooth LE, Bluetooth Mesh, NFC, Thread and Zigbee

128 MHz Arm Cortex-M33 CPU with
1 MB Flash + 512 KB RAM
64 MHz Arm Cortex-M33 CPU with
256 KB Flash + 64 KB RAM
Bluetooth LE
Bluetooth Direction Finding
Bluetooth Mesh
Thread, Zigbee
ANT
NFC
Advanced security
USB, QSPI, HS-SPI
105 °C extended operating temperature
1.7-5.5 V supply voltage range

Read more

nRF52 Series

nRF52840 aQFN73 SoC nRF52840 SoC

Bluetooth SoC supporting Bluetooth LE, Bluetooth Mesh, NFC, Thread and Zigbee

64 MHz Arm Cortex-M4 with FPU
1 MB Flash, 256 KB RAM
2 Mbps, 1 Mbps, Long Range
Bluetooth LE
Bluetooth Mesh
Thread, Zigbee
+8 dBm TX Power
128-bit AES CCM, Arm CryptoCell-310
UART, SPI, TWI, PDM, I2S, QSPI, PWM
12-bit ADC
NFC
USB 2.0

Read more

nRF52833 SoC nRF52833 SoC

Bluetooth SoC supporting Bluetooth LE, Bluetooth Mesh, Bluetooth Direction Finding, NFC, Thread and Zigbee

64 MHz Arm Cortex-M4 with FPU
512 KB Flash, 128 KB RAM
2 Mbps, 1 Mbps, Long Range
Bluetooth LE
Bluetooth Direction Finding
Bluetooth Mesh
Thread, Zigbee
+8 dBm TX Power
128-bit AES CCM
UART, SPI, TWI, PDM
HS-SPI, I2S, PWM
12-bit ADC
NFC
USB 2.0

Read more

nRF52832 SoC nRF52832 SoC

Versatile Bluetooth SoC supporting Bluetooth LE, Bluetooth Mesh and NFC

64 MHz Cortex-M4 with FPU
512/256 KB Flash, 64/32 KB RAM
2.4 GHz transceiver
2 Mbps, 1 Mbps
Bluetooth LE
Bluetooth Mesh
+4 dBm TX power
128-bit AES
UART, SPI, TWI, PDM, I2S
PWM
12-bit ADC
NFC-A
Read more

nRF52820 SoC nRF52820 SoC

Bluetooth SoC with built-in USB and Bluetooth LE, Bluetooth Mesh, Thread and Zigbee support

64 MHz Arm Cortex-M4
256 KB Flash, 32 KB RAM
2 Mbps, 1 Mbps, Long Range
Bluetooth LE
Bluetooth Direction Finding
Bluetooth Mesh
Thread, Zigbee
+8 dBm TX power
128-bit AES
UART, SPI, TWI, QDEC
Full Speed USB 2.0
-40 to 105 °C extended temperature range
1.7 to 5.5 V supply voltage

Read more

nRF52811 SoC nRF52811 SoC

Bluetooth SoC supporting Bluetooth LE, Bluetooth Direction Finding and Thread

64 MHz Cortex-M4
192 KB Flash, 24 KB RAM
2.4 GHz transceiver
2 Mbps, 1 Mbps, Long Range
Bluetooth LE
Bluetooth Direction Finding
Thread
+4 dBm TX power
128-bit AES
UART, SPI, TWI, PDM
PWM
12-bit ADC

Read more

nRF52810 SoC nRF52810 SoC

Bluetooth SoC supporting Bluetooth LE

64 MHz Cortex-M4
192 KB Flash, 24 KB RAM
2.4 GHz transceiver
2 Mbps, 1 Mbps
Bluetooth LE
+4 dBm TX power
128-bit AES
UART, SPI, TWI, PDM
PWM
12-bit ADC
Read more

nRF52805 SoC front and back nRF52805 SoC

Bluetooth SoC supporting Bluetooth LE

64 MHz Cortex-M4
192 KB Flash, 24 KB RAM
2.4 GHz transceiver
2 Mbps, 1 Mbps
Bluetooth LE
+4 dBm TX power
128-bit AES
UART, SPI, TWI
12-bit ADC
Read more
See all

Compatible PMIC and RF FEM options

calendar nPM1100 PMIC

Ultra-small form-factor Power Management IC (PMIC) for charging batteries and power delivery

The nPM1100 is a dedicated power management IC (PMIC) with dual-mode configurable buck regulator and integrated battery charger. It is designed as a complementary component to Nordic’s nRF52® Series and nRF53® Series System-on-Chips (SoCs) to ensure reliable power delivery and stable operation, whilst maximizing battery life through high efficiency and low quiescent currents. It can also be used as a generic PMIC device for any other suitable application. Its extremely compact form factor makes it ideal for advanced wearables, connected medical devices, and other size constrained applications. PCB area usage can be as low as 23 mm2.
Read more

Front of an IC saying NPM1300, QEAAB0, 2302AC, with back showing QFN pads nPM1300 PMIC

Power Management IC (PMIC) with unique system management features

The nPM1300 is designed to provide highly efficient power regulation for Nordic’s nRF52 and nRF53 Series, as well as the nRF54L and nRF54H Series wireless multiprotocol Systems-on-Chip (SoC). The PMIC is also suitable for battery charging for applications based on the nRF91 Series systems-in-package (SiPs) for cellular IoT, by using the PMIC’s unregulated output to power the SiP's internal buck regulators.

Devices using the nPM1300 and a compatible SoC or SiP also get access to the Nordic Fuel Gauge, a highly accurate, ultra-low-power way of estimating state-of-charge of rechargeable batteries.

Read more

nPM2100_WLCSP_stacked_web.png nPM2100 PMIC

Power Management IC (PMIC) with ultra-efficient boost regulator for primary-cell batteries

The nPM2100 PMIC enables longer run-time on every battery by implementing toolbox of power saving capabilities for primary cell batteries.

The nPM2100 is designed to provide highly efficient power regulation for any primary-cell application, with exceptional software support for Nordic’s nRF52, nRF53, and nRF54 Series of wireless multiprotocol Systems-on-Chip (SoC) in the nRF Connect SDK. The nPM2100 is also suitable for use with non-Nordic host devices.

Read more

nRF21540 SoC nRF21540 RF FEM

RF front-end module (FEM) for Bluetooth® Low Energy, Bluetooth® mesh, 2.4 GHz proprietary and Thread and Zigbee

Supports Bluetooth® Low Energy, Bluetooth® mesh, Thread and Zigbee (802.15.4) and 2.4 GHz proprietary protocols

Tunable output power in small increments up to +21 dBm

13 dB RX gain with 2.7 dB noise figure

Two antenna ports for antenna diversity

TX gain control via I/Os, SPI, or a combination

-40 °C to 105 °C extended operating temperature range

1.7 to 3.6 V supply range

4x4 mm QFN16 package

Between 6.3-10x range extension when combined with an nRF52 or nRF53 Series SoC

Read more

nRF2220 RF FEM

Read more
See all
